• 2"  x 4"  11 gauge steel weight stack frame housing
• Form fitted outer weight stack shield
• Hi/Low adjustment column
• Easy lift adjustment handle
• Bright red colored pull knobs
• Instructional color placard
• Custom made rubber feet with bolt-down holes
• 150 lb. weight stack
• 1/4"  nylon coated aircraft cable driven. 4800 lb. test
• Chin up station
• Commercial Grade Fitness Equipment
• 168" L x 55" W x 92" H
• Weight: 630 lbs
• Great addition for any home or commercial gym
• Exercise virtually every muscle group with one machine.
• You can interchange the cable handles to provide you with an unlimited number of exercises for all experience levels.

Raptor Series Standard Features:

• Adjustable positions on all machines to accommodate all users to ensure correct bio-mechanical function. Adjustments are made with Heavy Duty spring loaded colored pull-pin knobs.
• Weight Stacks are adjusted with a tethered, magnetic selector pin that extends through the entire weight stack.
• Cable system with 1/4" thick 4800 lb test military spec galvanized oil impregnated air craft cable finished with a tough nylon coating to 3/16" thick.
• Manual tension adjusters on every machine for the cable adjustments.
• Weight stack plates are solid steel machined precisely to with in an oz of weight.
• Weight stack is accessible from a seated position.
• Weight stacks are enclosed in full length shrouds.
• Weight system allows user to increase by 5 lb increments.
• Instructional guide charts used to inform correct usage for each machine along with anatomical highlights to show which muscle groups are being worked.
• Each machine is made with a lower starting weight stack and has counter-balanced arms when needed.
• Heavy-duty 40 oz. commercial grade marine Naugahyde upholstery which is 85% mildew resistant. High density closed cell foam reinforced by thick plywood backing for stable support.
• Exceeds all ASTM requirements.
• Guide rods are 1" CCRO ANSI 1045, solid steel hard chrome-plated with tensile strength of 75,000psi.
• Frames are constructed of High Stress 3/16" ASTM A-500 grade B structural steel tubing (11 gauge) 2"x4", 2"x3" tubing. 2"x3" tubing on all uprights, 2"x2"x1/8" ASTM A-500 grade B structural carbon steel tubing (11 gauge) is used on cross members and benches.
• All welds are ground down and stress tested.
• Custom color powder coat paint, 3 stage pre-paint preparatory process that includes a state of the art pellet blasting machine system that purifies steel. The steel is then sent through a preheat stage before the final magnetic paint powder is applied and baked for a long lasting hardened finish.
• Urethane foam grades are a minimal grading of HR-125 (density pcf of 2.60 +/- 0,10 and above in high-compression areas) and HR-150 (density pcf of 4.60 +/- 0.30).
• Cams are computer designed and laser cut to exact shape to allow proper variable resistance throughout the exercise complete range of motion. All cams are 1/4" thick solid steel. The cams are different for each machine to provide correct movement for the exercise.
• Shrouded pulley housing is 6"x1/4" thick solid steel.
• Pulley wheels are 4" and 6" solid fiberglass reinforced body with a 1/2" cable groove. Oil dipped double sealed racer ball bearings with a 1/2" axis shaft hole. Sealed for moisture and dust proof.
